Securnix ZA-8FA1205-F8 12V 5A 8-Channel CCTV Power Supply

Securnix ZA-8FA1205-F8 12V 5A 8-Channel CCTV Power Supply

Securnix 12V 5A 8 Channel CCTV Power Supply

More Info

The Securnix (Zatech) ZA-8FA1205-F8 is a compact 8-channel power supply for running up to eight CCTV cameras from a single mains point. It takes 200-240V AC input and delivers a 12V DC output rated at 5A, distributed across eight screw-terminal outputs rated at a maximum of 1A per channel. A selector switch sets the output to 12V, 13.5V or 15V (Normal, Long and Ex-Long), which compensates for voltage drop on longer cable runs so cameras at the far end of a property still get enough power. Esquire lists short-circuit, overload and over-voltage protection. The unit wall-mounts via its top tabs and suits analogue, HD-analogue or 12V IP camera installs in homes and small businesses. Mounting it near the DVR makes it easy to back up with a UPS or inverter through load shedding. With 5A total, plan on roughly 0.6A per camera when all eight channels are used, which covers typical fixed dome and bullet cameras.

R167.00

Online price incl. VAT

Availability: Stock available — ships within 1-3 business days

Power

  • Input: 200-240V AC, 47-63Hz (per unit label)
  • Output: 12V DC, 5A total
  • Output voltage select: 12V / 13.5V / 15V (Normal / Long / Ex-Long)
  • Channels: 8
  • Max per channel: 1A

Protection

  • Short circuit: Yes
  • Overload: Yes
  • Over-voltage: Yes

General

  • Outputs: Screw terminal block
  • Mounting: Wall mount
  • Model: Zatech ZA-8FA1205-F8
  • Warranty: 6 months (per Esquire)
