Stage Plus Power Cube 32-16 - 32 in - 30mA ELU - 12 x Amphenol HP (powerCON) C curve MCB Incl. Bag

Stage Plus Power Cube 32-16 - 32 in - 30mA ELU - 12 x Amphenol HP (powerCON) C curve MCB Incl. Bag
More Info

Stage Plus is a South African manufacturer of staging, rigging and power-distribution equipment, and the Power Cube is its compact portable distro for live events, outdoor broadcasts, film sets and rental companies. The metal enclosure has integrated handles and protective raised edging around the top panel, where the outlets and circuit breakers are located, so they are shielded from knocks on site. This model (SP-POW-PC-32316PC30) takes a 32A three-phase supply via a 32A male CEE Form inlet and passes it through to a 32A female CEE Form outlet for linking further units, while distributing single-phase power to twelve Amphenol HP (powerCON-compatible, 20A latch-locking) outlets. Protection is by a 63A four-pole RCD with 30 mA earth-leakage sensitivity and six 16A single-pole C-curve MCBs, and input monitoring lights with a voltage monitor show the status of each phase at a glance. The 30 mA RCD provides personnel-protection level earth-leakage sensitivity, suited to general stage, lighting and audio distribution. A 600 denier padded carry bag with shoulder strap is included. It must be connected by a qualified person to a correctly rated and tested three-phase supply.

R11,011.00

Online price incl. VAT

Availability: Stock available — ships within 1-3 business days

Input

  • Supply: 32A three-phase
  • Inlet: 32A three-phase male CEE Form
  • Link-through: 32A three-phase female CEE Form

Output

  • Outlets: twelve Amphenol HP (powerCON-compatible, 20A latch-locking) outlets
  • Output type: 16A single-phase

Protection

  • RCD: 1x 63A 4-pole, 30 mA
  • MCBs: 6x 16A 1-pole C-curve
  • Monitoring: Input monitoring lights with voltage monitor

Included

  • Bag: 600 denier padded bag with shoulder strap
